2000kg Per Day Automatic Floating Fish Feed Pellet Making Machine

Simple operation automatic fish production line is widely used for producing grains into high grade aquatic feed pellets for fish,catfish,shrimps,crabs,etc. The fish feed can float on the water surface without dissolution for over 12 hours.

The Flow chart of 2000kg per day automatic floating fish feed pellet making machine

Technical Parameters of  automatic floating fish feed pellet making machine

Different capacity for fish food making machine

For the fish feed machine,which need twin screw extruder,different model ,it has different production capacity:

SLG65-III for 150kg/hr

SLG70-II for 200-250kg/hr

SLG85-II for 400-500kg/hr

SLG95-II for 800-1000kg/hr

please tell me which capacity do you prefer ?

Sample of fish feed pellet:

Raw material of  automatic floating fish feed pellet making machine

Rice flour, corn flour, wheat flour, low temperature soya flakes meal, rice bran , wheat bran, fish powder, bone powder etc.

Some mainly parts of the process line

Mixer: material is stainless steel, to mix the raw materials evenly, fast speed, no leakage. including Single axle and double shaft mixer ,

Twin screw extruder(wet type/dry type) ： To extrude the raw materials and make them to the required shape and size of the fish feed pellets by mould  , SLG65, SLG70, SLG85 etc

Floating fish feed processing machine Series of Screw Extruder mainly consist of feeding system, extruding system, cutting system, heating system, lubricating system and controlling system.

Automatic lubricating and forced cooling make sure that extruder performs safely and extends using life.

Feeding system, extruding system and cutting system all adopt frequency conversion timing to gain powerful drive, stable perform, and electricity saving.

Screws are made of alloy and processed by special technique to possess high in-tensity, abrasion resistant.

By means of designing different structures and slenderness ratios according to needs of products, screw ex- truding system can meet different technology demands.

Dryer oven : the expanded food go through the "s" passage, to be dried to increase the self life.   heating way including electrical, steam, gas , choose the one that you prefer please

The automatic floating fish feed pellet making machine is a special equipment for baking snack food, modified starch and pet feed. By adjusting the temperature and the transmission speed of the frequency conversion belt, it can bake different kinds of food, modified starch and feed. The equipment has the advantages of high automation, space saving, energy saving, simple maintenance and long service life.

Floating fish feed processing machine Dryer is compact, has small dry area and a large superficial area. It features small scale of heat elimination & high thermal efficiency.
Mesh belt conveyors and thermal insulation boards all use stain-less steel material, making the equipment clean and sanitary.
The speed of mesh belt conveyor is adjustable. The drying period for food in the oven can be adjusted.
The automatic temperature control system makes it possible to set the temperature according to your needs.
These series of roasting oven are widely used, it is used for drying all kinds of stick, piece, grain etc. shape inflating snack food, the user can choose different types of dryer according to layer, length or energy.

Our service:

1.) Consultation service before, during,and after sales;
2.) Project planning and design service;
3.) Debugging of equipment until everything is functional;
4.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;
5.) Training of equipment maintenance and operating personally;
6.) New production techniques and formulas;
7.) Provide 1 year complete warranty and life-time maintenance service.

Packing:

inside plastic bag, outside wooden case for fried pellet snack food machine (Based on the customers' need adopt the wooden case or wooden pellets, etc.).

Delivery time:15-20 working day.

Our company , is a high and new technology enterprise integrating technology, manufacture and trade. We have devoted ourselves to developing, manufacturing and trading double/single screw extruders, snack production lines, breakfast cereal/corn flake production lines, soya meat production lines, pasta/macaroni production lines, pet food production lines, Floating fish feed processing machine etc.
We have  a comprehensive manufacturing program offering equipment and systems to customers in extruded snack food processing machinery and allied industries. We can supply individual items of equipment or complete factory layouts and lines, which are custom-built to meet the requirements of customers.
We are insisting on improving the standard of products and trying our best to serve our clients. Our goal is to become the biggest and best  food processing machinery manufacturer in China. We wish our products can benefit clients from all over the world.

Our automatic floating fish feed pellet making machines warmly welcomed by customers from all over the world like Peru, Mexico, Russia, Argentina, South Korea, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan
