Floating Fish Feed Machine

For fish feed product, the floating time in water can be adjusted by the extrusion degree adjustment. The final fish feed products have unique shape and good taste, high nutrition and smooth textures. For feeds of fish and shrimp. This dry type floating fish feed machine is an ideal for small and medium fish farm holders or feed processing plant.

Send Inquiry

Chat Now

Introduction of Floating Fish Feed Machine

Materials :wheat/ corn flour, born powder and so on;

Final feed: different shapes and sizes of dog food,cat food,fish feed etc;

Capacity of fish food equipment: 150kg/h, 250kg/h, 500-600kg/h,1-3ton/hr;

Consumption of fish food equipment: Low electricity and labor consumption.

Main Components of Floating fish feed machine extruder

* Power Drive System: It includes main motor and distribution box.

* Feeding System: The machine adopts arch-destroying feeding system to ensure even feeding and discharging.

* Extrusion System: It consists three parts: screw, barrel and connecting segment. Materials cooked with high temperature and high pressure.

* Heating System: Heating rings encircled on the barrel.

* Cooling System: Composed if water jacket, water pump and cooling pipeline.

* Lubrication System

* Electric Control System

Process of Floating Fish Feed Machine:
Milling system --- Mixing system --- Extrusion system --- Drying system ---Flavoring system ---Packing system

Technical Parameters of Floating Fish Feed Machine

Model	SLG65	SLG70	SLG85	SLG95
Installed Power	76Kw	95Kw	178Kw	280Kw
Production Capacity	140- 160Kg/h	240- 260Kg/h	500- 600Kg/h	1000Kg- 1200Kg
Dimension	160018002000mm	180020002200mm	250026003000mm	300032003500mm
