Panko Bread Crumbs Making Machines Breadcrumbs Production Line
Bread crumb equipment is mainly a twin-screw extruder, which can complete the production processes of traditional electrode bread crumbs, such as raw material mixing, dough mixing, grouping, passing through the machine (noodle press), fermentation, and maturation. It is a hot extrusion process with high temperature, high pressure, short time, and low moisture. Compared with traditional production processes, it has fewer production personnel, shorter production processes, higher unit output, energy saving and high efficiency, and lower production costs; simple equipment matching, small footprint, and easy operation; no waste, no sewage and waste gas generation, green and environmentally friendly, and no pollution; it uses a wide range of raw materials, is simple and easy to change product varieties and shapes, and has more diverse products.
Main Features for Panko Bread Crumbs machine
1) Panko Bread crumb machine Standard configurations: Mixer→ Screw conveyor→ Twin screw extruder→ Shaper→ Hoister→Miller→Sifter→ Air conveyor→Dryer→ Container→Vacuum feeder → Sifter
2) Panko Bread crumb machine Various products: Round ball, Circle ring, Bear, Star, Half moon, Curls, Flower, and Triangle, and so on.
Method to change the shape: We will design the specific shape which you want to produce accordingly.
1.Mixing powder machine: used for mixing raw materials with water. The mixing powder machine is vertical high speed, mixing evenly. 2.Screw feeder: transport the mixed raw materials to the hopper of the extruder
3.Twin-screw extruder: used for material expansion, different models for different output configurations
4.Cutting machine: used for product cutting. Variable frequency adjustable
5.Elevator: generally used for belt type and air conveying type, transported to the oven
6.Multi-layer Drying box: different drying boxes are configured for different output, generally: three layers of five meters, five layers of five meters, five layers of eight meters, seven layers of eight meters, etc. 7.Conveyor: convey the product to the chaff machine
8.Bran breaker: used for product crushing, suitable for making pellets, pin-shaped breadcrumbs and other breadcrumbs uniformly, and easy to clean.
Breadcrumbs production line main Features
1) Belt transmission between motor and gear box,reducing energy consumption.
2) Feeding,main driving device, and rotary cutting device adopt inverter to adjust the speed with more powerful drive, stable running, and low consumption.
3) Screw is made of alloy steel with long life.Segmental assembled screws are applied tomore kinds of materials and products
4) Automatic lubrication system can lower down power consumption and prolong the life.
5) Double screws feed equal materials forcibly.
6) Hanging mould and knives seat and bearing knife adjusting system can adjust the kniver exactly and swiftly.
7) Bread crumb machine Various products:
Round ball, Circle ring, Bear, Star, Half moon, Curls, Flower, and Triangle, and so on.
Method to change the shape: We will design the specific shape which you want to produce accordingly.
Packing and Shipping
1.Packaging Specification: Outside Package:
Wooden Packing as Exportand Standard.
2.Delivery time: 5-10 days after received 40% of the whole payment.
3.About Shipping: We can be reasonable for the shipping ,of course,we can also accept and cooperate with your agent if you have shipping forwarder in China.
